Autel MaxiSYS MS909

Autel MaxiSYS MS909

$5,450.00 AUD
$5,450.00 AUD
Sale Sold out
Shipping calculated at checkout.

MaxiSYS MS909 Diagnostic Tablet with MaxiFlash VCI/J2534

Introducing the MaxiSYS MS909, powered by an Octa-Core Processor, featuring a 10 Inch high resolution touchscreen tablet with Android 7/10 and a substantial 128 GB of built-in memory.

The MaxiSYS MS909 provides diagnostic guidance and component testing to confirm repairs. Equipped with the new MaxiFlash VCI, a combination VCI and vehicle communication tool providing faster dual Wi-Fi vehicle & network communications.

The Autel MaxiSYS MS909 features a 5MP front & 16MP rear camera and a rechargeable 15000 mAh battery capable of 8 HOURS continuous use ensuring you're always ready to scan!



Specifications

Operating System Android 7.0 / Android 10.0
Processor Samsung Exynos 8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53) / Qualcomm 660 Octa-core processor (2.2GHz Quad-core A73 + 1.8GHz Quad-core A53)
Memory 4GB RAM & 128GB On-board Memory
Display 9.7-inch TFT-LCD with 1536 x 2048 resolution & capacitive touch screen
Connectivity
  • Dual Wi-Fi (802.11 a/b/g/n/ac 2×2 MIMO)
  • BT v.2.1 + EDR
  • GPS
  • USB 2.0 (TWO USB HOST Type A, ONE USB mini device)
  • HDMI 2.0
  • SD Card (Support up to 256GB)
Camera
  • Rear: 16 Megapixel, Autofocus with Flashlight
  • Front: 5.0 Megapixel
Sensors Gravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output
  • Microphone
  • Dual Speakers
  • 3-Band 3.5 mm stereo/standard headset jac
Power and Battery
  • 15000mAH 3.8V lithium-polymer battery
  • Charging via 12V AC/DC power supply with the temperature between 0°C and 45°C
Input Voltage 12V/3A Adapter
Operating Temperature 0 to 50°C (32 to 122°F)
Storage Temperature -20 to 60°C (-4 to 140°F)
Dimensions(W x H x D) 304.4 mm (11.98″) x 227.8 mm (8.97″) x 42.5 mm (1.67″)
Weight 1.66kg (3.66 lb.)
Protocols CANFD, DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)



Why Autel?

  1. Regular Autel Updates, providing the latest OE level coverage for over 80 US Domestic, Asian and European vehicles.
  2. Leading edge OE level functionality including comprehensive OBDII diagnostics, service procedures and advanced ECU coding & programming.
  3. Automatic system and software updates.
  4. Interactive Data Logging sessions enable direct contact with Autel support for rapid troubleshooting of bugs and errors.
  5. One-stop multitasking enhances the management of workshop operations to maintain all data files, customer information and vehicle records.
  6. Cloud-based Data Manager stores customer and vehicle records, scanner data and technician notes.
